TECHN I CAL SPEC I F I CAT I ONS
AC INPUT DATA
NOMINAL AC VOLTAGE (GRID | GENERATOR) 120/240VAC; 120/208VAC (L1/L2/N required)
FREQUENCY (GRID | GENERATOR) 60 Hz (Default) | 50 Hz (Configurable)
GRID MAX. CONTINUOUS AC CURRENT 100A @ 240VAC
MAX. AC INPUT POWER 24000W
GENERATOR MAX. CONTINUOUS CURRENT 62.5A @ 240VAC
RECOMMENDED GENERATOR CAPACITY 6000W – 15000W
AC BYPASS (GRID | GENERATOR) 100A | 90A
AVAILABLE FAULT CURRENT 5kA
INPUT SHORT CIRCUIT CURRENT 150A peak @100us, per inverter
AC OUTPUT DATA
OUTPUT VOLTAGE 120/240VAC; 208VAC
OUTPUT FREQUENCY 60 Hz (Default) | 50 Hz (Configurable)
MAX. CONTINUOUS OUTPUT CURRENT* 62.5A @ 240VAC | 62.5A @ 208V
NOMINAL POWER OUTPUT* w/ PV: 15000W @ 240V | 13000W @ 208V
w/ out PV: 12000W @ 240V | 12000W @ 208V
MAX. CONTINUOUS WATTAGE 15000W (L1-L2) | 7500W (L1-N or L2-N)
PEAK POWER (SURGE CAPACITY)** 15360W for ≈10s
POWER FACTOR VALUE .99
THD (V) <3%
SWITCHING TIME <10 ms @ Single / <20 ms @ Parallel
PV INPUT DATA
NUMBER OF MPPTS 2
INPUTS PER MPPT 2/2
MAX. USABLE INPUT CURRENT 35A/35A
MAX. SHORT CIRCUIT INPUT CURRENT 44A/44A
DC INPUT VOLTAGE RANGE*** 100 – 480 VDC
MIN. STARTUP VOLTAGE 100 VDC
MPPT OPERATING VOLTAGE RANGE 120 – 385 VDC
NOMINAL MPPT VOLTAGE 320 VDC
MAX. PV INPUT VOLTAGE*** 500 VDC
MAX. UTILIZED SOLAR POWER 24000W (12000 per MPPT)
MAX. RECOMMENDED SOLAR INPUT 28000W (14000 per MPPT)
*15kW nominal power output with model #: IV-15000-XP-IN-01 only. Previous models are limited to 12kW nominal output wit
